3D skaneris Shining 3D Einscan SP v2

Nav noliktavā

(Atzīmējiet 2-4 preces no kategorijas)

EINSCAN SP V2

Shining 3D has engineered and developed EinScan SE (Elite) and EinScan-SP (Platinum), with unique different specifica­tions to meet most applications’ requirement. Includes dual scan modes: Auto Scan and Fixad Scan. Manages a wide scan range from small to large. Scan in color, easy reconstruction of the real physics feature of an object.

EINSCAN-SP – COMPLETES THE MODEL RANGE

The EinScan-SP is the next generation of EinScan-S with its new design and upgraded capacity. Model SP fills a product gap between the more basic EinScan-S model and the more advanced EinScan-Pro. EinScan-SP is both easy to use, but also delivers fast, high resolution and reliable 3D scan data, perfect for development engineers, designers and mechanical engineers.

Some EinScan-SP features:

  • Time needed for a single scan: 1 seconds
  • Time needed for a 360° scan in Auto Scan mode: 45 seconds
  • Plug-and-play. Easy set-up with automated calibration
  • Uses a safe structured white light, no laser or other light source that requires protection glasses



Scan Mode Auto scan Fixed scan
Scan Speed 1 min. 4 s
Mode of Alignment Feature; Manual Turntable; Manual
Single Shot Accuracy ≤ 0.05 mm ≤ 0.05 mm
Maximum Scan Volume / Minimum Scan Volume 200 x 200 x 200 mm / 30 x 30 x 30 mm 1200 x 1200 x 1200 mm / 30 x 30 x 30 mm
Range of Single Capture 200 x 150 mm 200 x 150 mm
Point Distance 0.17 mm ~ 0.2 mm 0.17 mm ~ 0.2 mm
Texture Yes Yes
File Format OBJ, STL, ASC, PLY OBJ, STL, ASC, PLY
Camera Resolution 1.3 Megapixel 1.3 Megapixel
Light Source White Light White Light
Stand-off Distance 290 ~ 480 mm 290 ~ 480 mm
Computer Requirements • Graphic Card: NVIDIA GTX 660 or higher > 2 GB

• Interface: 1 x USB 2.0 or 3.0

• Operating system: Win 64 bit

• CPU: Dual-core i5 or higher

• RAM: > 16 GB

• Graphic Card: NVIDIA GTX 660 or higher > 2 GB

• Interface: 1 x USB 2.0 or 3.0

• Operating system: Win 64 bit

• CPU: Dual-core i5 or higher

• RAM: > 16 GB

Weight unpacked / packed 4.2 kg / 7.0 kg 4.2 kg / 7.0 kg
Dimension 570 x 210 x 210 mm 570 x 210 x 210 mm
Power Supply 50 W 50 W
Input Voltage DC: 12 V / 3.33 A DC: 12 V / 3.33 A
Calibration Board HD HD
Turntable Turntable with markers Turntable with markers
Load Capacity of Turntable 5 kg 5 kg

Video

EinScan-SE & EinScan-SP - Desktop 3D Scanner
